Description
The LGK 100A PRO Inverter Air Plasma Cutter is a portable metal cutting tool that uses compressed air and high-frequency electric arcs to cut various metals, including steel and aluminum. It’s known for its compact design, user-friendly controls, and suitability for metalworking applications. Specific features may vary by manufacturer and model. Safety precautions are essential when using this equipment due to the high temperatures involved.
ADVANTAGE OF THE PRODUCT
The LGK 100A PRO Inverter Air Plasma Cutter advantage:
- Precision Cutting : Provides precise and clean cuts for detailed metalwork.
- Versatility : Can cut various metals, including steel, aluminum, and stainless steel.
- Portability : Compact and lightweight design for easy transport and maneuverability.
- Efficiency : Faster and more efficient than some other cutting methods, reducing production time.
- Less Heat-Affected Zone : Generates a smaller heat-affected zone, reducing the risk of material distortion.
- Lower Operating Costs: Energy-efficient inverter technology can lead to reduced energy consumption and operating costs.
| SPECIFICATION LGK 100A PRO | ||
| CUT | MMA | |
| Standard Input Voltage | 3P AC380V±10% | |
| Rated Input Capacity | 15 KVA | 13 KVA |
| Rated Input Current | 27A | 24A |
| No-load Voltage | 275V | 60V |
| Current Adjusting Range | 50-100A | 20-320A |
| Max. Cutting Thickness | <35 mm | <15 mm |
| Suitable Electrode | — | 3.2-5.0 |
| Frequency | 50/60 Hz | |
| Duty Cycle | 60% | |
| External Gas Pressure | 0.3-0.5 Mpa | |
| Internal Gas Pressure | 0.3-0.4 Mpa | |
| Case Protection Degree | IP215 | |
| Arc Starting | Non Touch | |
| Overall Dimension | 625 x 302 x 585 mm | |
| Weight | 48 Kg | |
