Description
The QBY25AN is a compact air-operated diaphragm pump that is commonly used to transfer liquids such as water, oil, and chemicals. It is driven by compressed air and features a diaphragm that moves back and forth to create suction and discharge fluid through the pump’s outlet. It is a versatile and efficient pump that is suitable for a wide range of applications.
The Advantage of Air Operated Diaphragm QBY25AN :
- Air-operated, suitable for use in hazardous environments
- Self-priming, can run dry without damage
- Corrosion-resistant material construction
- Low maintenance and easy to repair
- Can handle a wide range of liquids, including viscous fluids and slurries
- Can handle solids up to 2.5 mm in diameter
- Adjustable flow rate and pressure
- Suitable for use in various industries
| SPECIFICATION OF AIR OPERATED DIAPHRAGM PUMP QBY25AN | |
| Diam | 25 mm |
| Head | 70 m |
| Flow | 0-2.4 m³/h |
| Max Air Pressure | 7 KGF/CM³ |
| Max Grain | 2.5 mm |
